Equipment Upgrade

1. Magnification: 1X
2. Field of View (FOV): 40° ± 2°
3. Objective Lens: 26mm F1.25
4. Diopter Range: -6D to +2D
5. Exit Pupil Distance: 25mm
6. Focusing Range: 25mm to +∞
7. IIT Generation: High-Speed Automatic Gate-Controlled Super Generation 2+
8. Performance (Resolution @ Signal-to-Noise Ratio): 64 lp/mm @ 29 SNR, 60 lp/mm @ 22 SNR
9. Gain: 10,000 to 33,000 cd/㎡/lx
10. Dimensions: 107 (L) × 110 (W) × 84 (H) mm
11. Weight (including battery): 460g
12. Power supply and operating time: Single AA battery inside the body @ 20h / External battery box @ 50h
13. Protection rating: IP67
14. Operating temperature: -40°C to +55°C
15. Storage Temperature: -55°C to +70°C
16. Auxiliary Lighting: LED 850nm
17. Attitude Sensing: Power off when flipped up / Power on when flipped down / Automatic shutdown after 10 minutes of inactivity or drop
