Equipment Upgrade

1. Magnification: 1X
2. Field of View (FOV): 40° ± 2°
3. Objective Lens: 26mm F1.25
4. Diopter Range: -6D to +2D
5. Exit Pupil Distance: 25mm
6. Focusing Range: 25mm to +∞
7. IIT Generation: High-Speed Automatic Gate Control Super Generation 2+
8. Performance (Resolution @ Signal-to-Noise Ratio): 64 lp/mm @ 29 SNR, 60 lp/mm @ 22 SNR
9. Gain: 10,000 to 33,000 cd/㎡/lx
10. Dimensions: 105 (L) × 69 (W) × 57 (H) mm
11. Weight (including battery): 285g
12. Power supply and continuous operating time: Single AA battery @ 30h (zero power consumption in standby mode)
13. Protection rating: IP67
14. Operating temperature: -40°C to +55°C
15. Storage temperature: -55°C to +70°C
16. Auxiliary lighting: LED 850 nm
17. Attitude sensing: Power off when flipped up / Power on when flipped down / Automatic shutdown after a fall or 10 minutes of inactivity
