Equipment Tools

1. Infrared resolution: 640×512@12um
2. Wavelength range: 7um ~ 8.5um
3. Thermal sensitivity: ≤30mk
4. Field of view (FOV): 12.6°× 10°
5. Lens focal length: 35 mm motorized zoom
6. Sensor type: 1/2.8-inch CMOS
7. Horizontal resolution: ≥1100 TVL
8. Minimum illumination: Color (Colored): ≤ 0.001Lux@F1.5
Black and White (Black and White): ≤ 0.0001Lux@F1.5
9. Gain control: Automatic/Manual
10. Signal-to-noise ratio: 55dB
11. Focusing lens: 4.7nm to 141mm
12. Digital zoom: 16×
13. Field of view (FOV): 66° to 2° (±5%)
14. Optical zoom: 30×
15. F/#: 1.5 to 4.8
16. Detection Range/Sensitivity/Distance: 0–50,000 ppm.m / 50 ppm.m / ≤100 m
17. Output Interface: RS485 / RS232
18. Operating Temperature: -40°C to +60°C
19. Protection Rating: IP66/IP68 (2 m/2 h)
