Equipment Upgrade

1. Motorized zoom: 100mm to 120mm
2. Spatial resolution IFOV: ≥1.8mrad
3. System laser divergence angle: ≤2°
4. Deep-cut narrowband filter: 0D9@878.6nm±3nm
5. IIT Generation: Gen2+
6. Resolution @ Signal-to-Noise Ratio: 60 lp/mm @ 22 SNR
7. Gain: 10,000 to 33,000 cd/m²/lx
8. Central Wavelength: 878.6 nm ± 0.5 nm
9. Spectral Width FWHM: 0.5 nm
10. Peak power: 350W
11. Anti-reflection wavelength range: 1030nm to 1200nm
12. Pulse width: 20ns to 200ns
13. Repetition rate: 500kHz to 700kHz
14. Resolution and frame rate: 720P @ 25fps
15. Dynamic range: 72 dB
16. Power supply: External power supply from the drone
17. Continuous operating time: 0.5 hours
18. Weight: ≤4 kg
19. Operating temperature: -25°C to +60°C
