Logistical Support

Equipment dimensions: 3460mm × 2000mm × 2000mm
Maximum forming dimensions: 1500mm × 1000mm × 1000mm
Weight: 5500kg
Power supply: 380V, 50Hz, 20kW
Maximum forming efficiency: 1200 cm³/h
Maximum flatness: 0.2 mm/m
Manufacturing accuracy: deformation within 5 mm/m
Defect level: no more than 0.8 mm
Processable materials: Titanium alloys, aluminum alloys, steel, and non-metallic materials, etc.
Wave resistance rating: Capable of normal operation under simulated 5.5-grade sea conditions
