Augard/Ligard  Transparent  Armor  is  designed  to  provide transparent  and  lightweight  protection  for  military  armored personal   carriers(APC),light   armored  vehicles   (LAV).It   is made  with  asymmetrical  multi-layer  laminated  glass  clad polycarbonate,with a variety of constructions to defeat a wide range of threat levels against handgun,assault rifle projectiles, improvised  explosive  devices(IEDS)and  artillery  fragments, at minimum weight and thickness.

Features ofAugard/Ligard Transparent Armor:

• Distortionfreewindshield for safe and comfortable driving.
• Heateddeicing/defoggingwindscreens with ITO coating or

wiggle wire mat,to melt 3mm ice at-43C within 15 mins.

• Stealthyto K,X,C radar band.
• Optionof borosilicateglass and AIMgO4 transparent ceramics for significant lighter weight.Glass Weight And Performance


  Product Code	Protection Level	Ballistic Threat	Glass Weight	Glass Thickness
  Augard-S1	STANAG4569 LevelI	7.62x51mm NATO Ball 5.56x45mm SS109 5.56x45mmM193	88kg/m²	39mm
  Ligard-S1			75kg/m²	36mm
  Augard-S2	STANAG4569 LevelIⅡ	7.62x39mm APIBZ	144kg/m²	61mm
  Ligard-S2			120kg/m²	58mm
  *** Cigard-S2			60kg/m²	30mm
  Augard-S3	STANAG4569 Level II	7.62x51mm AP(WC) 7.62x54mm B32API	179kg/m²	92mm
  Ligard-S3			151kg/m²	88mm
  Cigard-S3			78kg/m²	36mm
  Augard-127		12.7x114mm APIMK211	234kg/m²	103mm
  Augard-S4	STANAG4569 LevelIV	14.5x114mm API/B32	336kg/m²	148mm
